Hey There, What’s That Sound? – Microphone Feedback
We continue with the Harmonica Microphones series with some thoughts on the knotty problem of microphone feedback: what it is and how to minimise it.
Feedback is that awful loud screeching, humming and/or whistling sound a system makes when a microphone picks up the sound from the amplifier’s speaker and sends it back to the amplifier for further amplification. Every system (in this case a microphone plus amplifier) has a feedback threshold. Turn the volume up loud enough and feedback occurs. Keep the volume below that point and it doesn’t. Unfortunately we often need to have our volume very close to the feedback threshold in order to be loud enough, and so feedback can come and go as conditions change. But some setups are less prone to feedback than others, and some microphones are less prone than others.
Factors influencing feedback are:
- Gain of the amplifier
- Distance of microphone from speaker (amplifier or PA, house or monitors)
- Tone settings
- Player technique
- Directionality of microphone
- Sensitivity of the microphone
What can be done about feedback?
Believe it or not, microphone choice is not very important. Many players believe one microphone is more sensitive to feedback than another, only because that microphone is louder/hotter/more sensitive than another. The only “fair” way to judge one mic vs. another is to adjust the amplifier’s volume so that the sound out of the speakers is equally loud from mic A to mic B, and then see which one more readily produces feedback.
Vocal mics and instrument mics are designed to be “directional” – to pick up more sound from the front than from the sides or the rear, specifically to help avoid feedback on stage. So a well designed microphone can help with a feedback problem – but only when it is in free air – in a rack or on a stand, and not in your hands. Once you pick up a microphone and cup it, all bets are off. If you hand hold a mic, feedback will be more of an issue because the mic is moving around and facing different directions. When you move your “cup” away from your face, it can act like a satellite dish and can catch and reflect more sound to the mic than if it was in truly free air. Your hands also destroy a good deal of the directionality designed into the mic. Many players learn to manage this by pressing the face of the mic against their chest while not playing. Ideally, you should be set up just a little further from “the hairy edge” of feedback so it isn’t too difficult to manage.
When you play acoustically, you can help to control feedback by ensuring that little to none of your sound is coming through the monitors. Depending on the frequency of the feedback, equalization (tone control) can help as well. When you’re playing amplified, all of the above applies. However the gain of your amplifier is the most important variable in taming a specific system. A microphone is designed specifically to pick up sound waves from the air, so it is a much more sensitive and troublesome feedback device than a guitar string. Consequently guitar amplifiers (and most harp amps start out as guitar amps) are set up with much more gain than we need. This allows the guitar player to get Hendrix-like feedback when he or she wants it, but it can be a nightmare for a harp player.
A change of mic might give you, at best, 1-2 dB more volume before feedback. A change of amp might be good for 10-15 dB, or even more.
Reducing feedback by reducing gain – amplifier tube substitution
Generally you can’t adjust the gain of a solid state amplifier. However we can usually substitute lower gain tubes for higher gain ones in a tube amp’s preamp section – and this can instantly make an amp more harp friendly. The most popular preamp tunes are the 12A# series. A typical Fender guitar amp has three tubes in the pre-amp section, and all are 12AX7’s as the amp comes from the factory, set up for electric guitar. Here are the gain factors of the 12AX7 and its compatible cousins:
GAIN FACTOR 100: 12AX7 – aka ECC83, 7025, ECC803, E83CC, 6681
GAIN FACTOR 70: 5751
GAIN FACTOR 60: 12AT7 – aka ECC81, 6201, 6679
GAIN FACTOR 45: 12AY7 – aka 6072
GAIN FACTOR 41: 12AV7 – aka 5965
GAIN FACTOR 19: 12AU7 – aka ECC82, 5963, 5814, 6189
As you can see, three 12AX7’s creates a huge amount of gain. On an amp like this, you will likely not get the “normal” channel volume past 2 before feedback. If your amp has an “overdrive” channel it will be completely unusable. There are way too many combinations and permutations to describe here, but here is one recipe for success: On a Fender Bassman type amp with three preamp tubes, replace the two 12AX7’s closer to the amp’s center with 12AU7’s. This should make a significant difference. If it isn’t enough, replace the outer one with a 12AT7 or 5751. You should now be right in the ball park and grasp the concept – continue to experiment and pick what you like.
Although reducing the gain of your amp makes it more manageable, it will not perform miracles. A Fender Blues Jr. sounds ear-splittingly loud in your living room. Yet you get on stage at a jam and wonder why it can’t be heard. So you turn it up until it is feeding back and conclude that you have a feedback problem. But you don’t. You have an amplifier problem.
Get a bigger amp!
More power helps, but I’ll let you in on a little secret. More speakers is just as important, or more so. Compare the surface area of the speakers on different amps. A Blues Jr. is a 15 watt amp with a single 12” speaker – if you do your maths you’ll know it has 113 sq. in. of speaker surface area. My Sonny Jr. Cruncher is about 35 watts, and has a 12” and two 8” speakers. That’s 213.5 sq. in of speaker surface area – more than twice as much power and almost twice as much speaker area. But even that isn’t always loud enough at some of the jams I go to. I can get the volume on that amp to 9 with no feedback. If I want to be heard at a jam, I bring out the big guns. My Sonny Jr. Super Sonny amp has about 50 watts, and has four 10 inch speakers (here’s Sugar Ray Norcia using one to fine effect). A little more power, but another big jump in speaker surface area – 314 sq. inches to be exact. The difference is huge. Room filling volume, and again, no feedback!
Other feedback management tips
Avoid “overdrive” amplifier channels or pedals: generally speaking these work by adding lots of gain and will be feedback nightmares. If you’re using a PA system and your amplifier is mic’d, tell the sound guy to take you out of the monitors completely. If you can’t hear yourself on stage, and getting closer to (or further from) your amp doesn’t help, have him sneak a tiny bit back in. Change where you stand. Turn the treble or mid-range down. Use an “anti-feedback” pedal. If none of that cures your feedback problem, you are simply asking more of your amp than it can deliver. The bigger the amp and the more speakers it has, the more likely it is that you can get good volume before feedback, regardless of which mic you choose!
Volume controls
And finally, get a volume control! There is nothing worse than getting everything all set during sound check, and then encountering feedback during your performance. But this happens all the time, because room conditions change for a variety of reasons (the sound man included). You certainly don’t want to have to dive for your amp to adjust it, knowing the feedback problem will be worse when you get closer. A volume control at the mic is the perfect solution to this problem. You can instantly kill feedback from where you stand just by lowering the volume a bit. When you perform, you often can’t be sure where the feedback is coming from, and a volume control tells you whether it is you or not.
Volume controls are useful tools even if feedback isn’t an issue. Although any good player has good dynamic control over his instrument, there can still be a wider dynamic range in your playing and with the band than you can accommodate merely by playing softer. Being able to back the volume off right at the mic is really nice when you’re comping behind a quiet passage in the music. You can also use a volume control to explore the tonal range of your amp, when otherwise you’d be firmly in feedback territory. An amp turned up to 10, with the mic’s volume controlled by you to remain below the feedback threshold, will sound different than the same amp at 6 with the volume control on the mic all the way up.
Some players pooh-pooh volume controls. Don’t listen to them. Practically every pro player I have seen uses a volume control. Charlie Musselwhite, Kim Wilson, Rod Piazza, Jason Ricci, Rob Paparozzi, Billy Branch, Curtis Salgado, Mark Hummel… the list just keeps on going. All of them use volume controls.
Feeling tied to the stage by your mic lead? We have the solution: for our last article in this series, we’ll be talking about going ‘wireless’.
Greg Heumann is curating our Harmonica Microphones section. Read his previous articles here. You can find more from him at www.blowsmeaway.com.
At a recent jam (electric guitar, electric bass, drums and harp), the quarters were comfortably cramped (host guitar players home studio), so I ended up about a yard (36 inch US measure) from the amp my Red Howler was sharing with lead guitar. The Howler has a volume knob, so I had control, but there comes a point where sharing a limited space with three other instruments, you’ve gotta make a decision between being heard, and “dealing” with the feedback. As for myself, once I got the hang of “playing” the feedback (as though it were a wrist-controlled “effects pedal”), the normally disturbing phenomenon actually added to my appreciation of our overall product. Not only was my harp feeding back, but the lead guitar also–and this only added to the “drive’ of the effect.The feedback was not constant, so when it did occur, I could choose to “play” it, or cut it. The method that seems to work best, is to un-cup my hands and quickly jerk the mike out of a direct “line of sight” path to the amp’s speakers.
Cheers!
Thanks Charles – playing the feedback is a show stopping trick used by players such as John Popper. Have you tried producing the feedback, then playing a blow note, bend or tonic that turns it into a musical extension of the harp? ROCK AND ROLL!
Buy a Kinder AFC+ (anti-feedback control). A truly amazing device. I can now stand next to my amp, hear what I’m playing and have the lead guitarist ask me to turn down because I’m way too loud!
